Shure ULX-D®

Shure ULX-D Digital Wireless offers uncompromising 24-bit audio clarity and extremely efficient RF performance with single, dual, and quad channel receivers for any size professional sound reinforcement application.

Scalable, intelligent hardware delivers the best performing digital wireless available, with a wide selection of trusted Shure microphones to choose from. Unmatched spectrum efficiency enables a dramatic increase in the number of simultaneous active transmitters on one TV channel, with rock-solid signal over the entire range. Optional rechargeable accessories eliminate the need for disposable batteries while offering extended run time and metering accuracy in hours and minutes. For secure transmission, all ULX-D components include AES-256 encryption.

Generations ahead of any other available system in its class, ULX-D brings a new level of performance to professional sound reinforcement.

Read our blog post Wireless Audio Software Trends and Shure Updates for a rundown on how Wireless Workbench® and ShurePlus™ Channels software enhance the capabilities of Shure wireless systems and make remote monitoring easier.

Learn more about the reasons to choose UHF or VHF in our blog post The Search for Spectrum: Wireless Systems in the VHF Band.

Uncompromising Digital Wireless Audio

• 24-bit/48 kHz digital audio that delivers incredibly clear and accurate reproduction of the source material
• 20 Hz–20 kHz frequency range with flat response
• Greater than 120 dB dynamic range through the analog outputs
• 130 dB dynamic range (typical) using Dante and AES67 digital networked audio
• 60 dB of adjustable system gain easily accessible from the receiver front panel
• No transmitter gain adjustments needed: optimized for any input source
• Wide selection of trusted Shure Microphones

Extremely Efficient and Reliable RF Performance

• Up to 64 MHz overall tuning range (region dependent)
• Up to 17 active transmitters in one 6 MHz TV channel (23 on an 8 MHz TV channel)
• High Density mode enables up to 47 active transmitters in one 6 MHz TV channel (63 in one 8 MHz TV channel), with no audio quality degradation
• Rock-solid signal stability with no audio artifacts over the entire 100 meter line-of-sight range using standard supplied ½ wave antennas
• Selectable 1, 10, and 20 mW transmitter RF output power (comparable to 5 times the analog RF output power equivalent)
• Optimized scanning automatically finds, prioritizes, and selects the cleanest frequencies available

Scalable, Intelligent Hardware

• Single (half-rack), Dual, and Quad (full-rack) receiver form factors for any size installation
• AES 256-bit encryption equipped for secure wireless transmission
• Ethernet networking for streamlined setup across multiple receivers
• Wireless Workbench® 6 software compatible for advanced frequency coordination, monitoring, and control
• Comprehensive 3rd party control and monitoring across subnets
• AXT600 Axient® Spectrum Manager compatibility
• Rugged metal housing on both transmitters and receiver
• Dual and Quad receivers additionally feature:
  • RF cascade ports, internal power supply, and dual Ethernet ports
  • Dante and AES67 digital networked audio over Ethernet
  • Bodypack frequency diversity ensures uninterrupted audio for mission-critical applications
  • Audio summing routes audio signal to multiple outputs

Shure Advanced Power Management

• Adapted from industry-leading Axient rechargeable technology
• Lithium-Ion chemistry and intelligent Shure battery circuitry results in rechargeable batteries with zero memory effect and precision metering
• Provides ULX-D transmitters with unmatched 11+ hours of performance time
• Transmitters and receivers display remaining battery life in hours and minutes accurate to within 15 minutes
• AA backwards compatibility

Shure Product Benefits

How It Works

ULX-D pushes wireless audio further. More streamlined. Higher density. Up to 47 systems running simultaneously within 6 MHz. That’s one reason it’s become the standard bearer for installed digital wireless. And you can hear it in crystal clear performances around the world.

Quality that’s in the Details

• Multiple spectrum options, including VHF, UHF, 900 ISM, 1.2 GHz (Japan only), and 1.5 GHz and 1.8 GHz (Europe only)
• Multiple transmitter types including handheld, bodypack, boundary, and gooseneck options
• Choice of receiver type (single, dual, or quad)
• Monitoring and control functionality from Wireless Workbench® 6, SystemOn, and ShurePlus™ Channels apps.
• Dual and quad receivers include DANTE™ digital audio networking
• Dante Domain Manager (DDM) compatible for managing enterprise-wide Dante audio network deployments

Why It’s Better

True to the source

The 24-bit digital audio and the wide frequency response capture the sound as clearly and accurately as it was produced.

Scalable control

The network is always yours to command with proven Shure tools like Wireless Workbench®, SystemOn, Axient Spectrum Manager, as well as AMX & Crestron integration and Dante audio.

Secure sound

Confidentiality is ensured via AES-256 encryption that generates a randomized key for each use.

Networked, intelligent charging

ULX-D transmitters use either AA batteries or our intelligent rechargeable solutions for up to 9 hours of use. Battery life and charge status can be monitored remotely from Shure software. So power is always on your side.
